Cummins genset 160kW, Cummins generator Philippines

Cummins Power Generator 200kVA, 160kW Diesel Generator

A-C220 / PRP: 200kVA , ESP: 220kVA

Main Specification:
Standby Power: 220kVA/ 176KW
Prime Power: 200/160 (KVA/KW)
Consumption 100%: 45L/H
Open Type Dimension (L×W×H) : 2654 X 1156 X 1595 mm
Weight: 1600KG
Open Type Dimension (L×W×H) : 3500 X 1126 X1700mm
Weight: 2400KG

Quantity

Contact Now

add to cart

Specification

Generator Set

Max. Power: 220kVA / 160kW
Rate Power 200kVA / 160kW
Rate Voltage 230/400V
Dimension For Open-type Genset: 2654 X 1156 X 1595mm
Weight For Open-type Genset: 1500kg
Dimension For Soundproof Genset 3200 X 1080 X 1500mm
Weight For Soundproof Generator 2200kg

Engine
Engine Manufacturer: Dongfeng Cummins Engine Co., Ltd.
Engine Brand: Cummins
Engine Model: 6CTAA8.3G2
No. of Cylinder: 6 Cylinder in line
Aspiration: Turbocharged and Air to Air Aftercooled
Governor: Electric
Engine Max. Output Power: 201kW

Alternator

Alternator Model: ASF274H
Alternator Brand: Hosem
Insulation: Class H
Phase: 3 Phase
Automatic Voltage Regulation: SX440
Protection Grade: IP23

The generators are designed to deliver reliable power with minimal noise, making them ideal for use in residential areas, hospitals, schools, and other noise-sensitive environments.

Our silent generators feature advanced soundproofing technology, ensuring that they operate at a noise level that won't disturb your peace or your neighbors. They are also built to last, with high-quality components and a rugged design that can withstand the toughest conditions.

At the heart of our silent generators is Cummins Power Systems, a global leader in power generation technology. With a reputation for innovation and reliability, Cummins Power Systems is a trusted name in the industry, and our generators are built to meet their exacting standards.

So whether you need a backup power solution for your home or a reliable power source for your business, our silent generators powered by Cummins Power Systems are the perfect choice. Contact us today to learn more about our products and services.

Standard Configurations

• Virtual load cabinet
• Stainless galvanized zinc plates with strong corrosion resistance
• Water jacket preheater, oil heater and double air cleaner, etc.

• Silence enclosure with thickness 2mm, triple powder coating, IR oven-cured paint. Stainless door lock and hinge

•Alternator excitation system: self-excited (AREP and PMG are optional)

•Maintainceless batteries with VARTA brand, and city power charger.

• Lockable battery isolator switch

• Vibration isolators between the engine/alternator and base frame

• Integrated wiring design

• Base fuel tank for at least 8 hours running

• Equipped with an industrial muffler

• 40℃ radiator (Silent Type), 50℃ radiator (Silent Type)

• Top lifting and steel base frame with forklift holes

• Drainage for fuel tank

• Complete protection functions and safety labels

Optional Configurations:

• ATS (automatic transfer switch) receptacle

• Remote control system

• Virtual load cabinet
• Stainless galvanized zinc plates with strong corrosion resistance
• Water jacket preheater, oil heater and double air cleaner, etc.

Details

Varta Brand Batteries High-efficiency Muffler Stainless Steel Door Lock Stainless Hinge

High-density Flame Retardant Lifting Ring and Step Ladder Forklift Holes Emergency Bottom

Sound-absorbing Cotton
