Deutz Diesel Generator Set 30kVA, 24kW Generator
A-DE33 / PRP: 30kVA , ESP: 33kVA
Main Specification:
Standby Power: 33/26 (KVA/KW)
Prime Power: 30/24 (KVA/KW)
Consumption 100%: 7.7L/H
Open Type Dimension (L×W×H) : 1650 X 700 X 1250mm
Weight: 635KG
Silent Type Dimension (L×W×H) : 2000 X 900 X 1250mm
Weight: 885KG
Standby Power: 33/26 (KVA/KW)
Prime Power: 30/24 (KVA/KW)
Consumption 100%: 7.7L/H
Open Type Dimension (L×W×H) : 1650 X 700 X 1250mm
Weight: 635KG
Silent Type Dimension (L×W×H) : 2000 X 900 X 1250mm
Weight: 885KG
Quantity
Specification
Generator Set
Max. Power: 33kVA / 26kW
Rate Power 30kVA / 24kW
Frequency 50Hz
Rate Voltage 230/400V
Dimension For Open-type Genset: 1650 X 700 X 1250mm
Weight For Open-type Genset: 635kg
Dimension For Soundproof Genset: 2000 X 900 X 1250mm
Weight For Soundproof Generator: 885kg
Rate Power 30kVA / 24kW
Frequency 50Hz
Rate Voltage 230/400V
Dimension For Open-type Genset: 1650 X 700 X 1250mm
Weight For Open-type Genset: 635kg
Dimension For Soundproof Genset: 2000 X 900 X 1250mm
Weight For Soundproof Generator: 885kg
Engine
Engine Manufacturer: Dalian Deutz Power Machinery Co., Ltd.
Engine Brand: Deutz
Engine Model: BFM3 G2
No. of Cylinder: 4 Cylinder in line
Aspiration: Naturelly Aspiration
Governor: Electrinic
Engine Max. Output Power: 32kW
Engine Manufacturer: Dalian Deutz Power Machinery Co., Ltd.
Engine Brand: Deutz
Engine Model: BFM3 G2
No. of Cylinder: 4 Cylinder in line
Aspiration: Naturelly Aspiration
Governor: Electrinic
Engine Max. Output Power: 32kW
Alternator
Alternator Model: ASF184G
Alternator Brand: Hosem
Insulation: Class H
Phase: 3 Phase
Automatic Voltage Regulation: SX460
Protection Grade: IP23
Alternator Brand: Hosem
Insulation: Class H
Phase: 3 Phase
Automatic Voltage Regulation: SX460
Protection Grade: IP23
Looking for a reliable and efficient generator to power your home or business? Look no further than our Deutz Generator 30kVA! With its powerful Deutz engine and advanced silent generator technology, this generator set is the perfect choice for those in need of dependable backup power.
Our Deutz Generator 30kVA is built to last, featuring a robust and durable design that can withstand the toughest of conditions. With a maximum output of 30kVA, this generator set is capable of powering a wide range of appliances and equipment, from small home appliances to large industrial machinery.
In addition, our Deutz Generator 30kVA features advanced silent generator technology, which reduces noise levels to a minimum, making it an ideal choice for use in residential areas, hospitals, and other noise-sensitive environments. This technology ensures that the generator operates quietly, without causing disturbance to nearby residents or employees.
Standard Configurations
• Silence enclosure with thickness 2mm, triple powder coating, IR oven-cured paint. Stainless door lock and hinge
• Alternator excitation system: self-excited (AREP and PMG are optional).
• Maintainceless batteries with VARTA brand, and city power charger.
• Lockable battery isolator switch.
• Vibration isolators between the engine/alternator and base frame.
• Integrated wiring design.
• Base fuel tank for at least 8 hours running.
• Equipped with an industrial muffler.
• 40℃ radiator (Silent Type), 50℃ radiator (Silent Type).
• Top lifting and steel base frame with forklift holes.
• Drainage for fuel tank.
• Complete protection functions and safety labels.
Optional Configurations:
• ATS (automatic transfer switch) receptacle.
• Remote control system.
• Virtual load cabinet.
• Stainless galvanized zinc plates with strong corrosion resistance.
• Water jacket preheater, oil heater and double air cleaner, etc.
• Stainless galvanized zinc plates with strong corrosion resistance.
• Water jacket preheater, oil heater and double air cleaner, etc.
Details
